NORDHAVN 625
Nordhavn 625
Overview
What helps keep Nordhavn at the top of its game is the continual push to move its designs forward. We have seen this in the past with the N52 (from the N47), the N60 and 63 (from the N55), the N68 (from the N64), the N76 (from the N72) and the N96 (from the 86). By refreshing existing hulls, it allows the company to efficiently introduce updated, modern offerings. The N625 will be a combination of what’s working incredibly well for Nordhavn right now: the new model is based on the very popular Nordhavn 60 and will employ some of the same bulk production techniques being used with the N41 and 51 builds.
Despite a number of Nordhavn 60 orders on the books, Nordhavn co-owner and Chief of Design Jeff Leishman saw an opportunity to further improvise the model’s proven hull. It has sustained extraordinary success beginning with the Nordhavn 55, and is also used as the basis of the Nordhavn 63. More than 100 of the hull’s three iterations combined have been sold. “It’s been a solid performer for us,” Leishman said. “I believed doing an update would provide us with another outstanding derivative.” The result is a fresh, modern exterior that’s in keeping with the sleeker feel Leishman has been injecting into his latest models.
The N625 will maintain the same footprint as the N60, but will also feel entirely different, said Leishman. As a result of his “cleaning up the lines”, the flybridge is slightly bigger, the windows in the cabins will be bigger, and some seating has been added to the foredeck. “It will feel lighter and brighter and give a sense of a bigger boat,” he said, even though size-wise, it’s nearly identical. Like the N60 and N63 before her, the N625 will have three cabins – two below and one behind the wheelhouse.
The N625 also takes a nod from the Turkish built N41 and N51 designs, utilizing a production boat-approach to ordering. She will have more equipment and features as standard which equates to a more resourceful buy. (Not included in the standard boat are tender and soft goods.) The spec won’t be as strict as her smaller sisters’ but certainly the boat won’t be as customizeable as the 60 and 63. Offering yachts with a complete or more-complete spec provides better building efficiency as well, Leishman said.
The boat will be built by Nordhavn’s partner factory, South Coast, at their brand new Taiwanese facility. South Coast, which also builds the N60, ventured into Taiwan in part to combat the Chinese tariff.
N625 Quick Specs
LOA: | 64' 8" (19.7 m) |
LWL: | 57' 3" (17.45 m) |
BEAM: | 18' 0" (5.49 m) |
DISPL.: | 138,000 LBS. (62.6) METRIC TONS) |
WATER CAPACITY (Approx.): | 600 GALLONS (2,271.2 LITERS) |
Photo Gallery
Exterior
Specifications
Standard Specs
LOA: | 64′ 8″ (19.7 m) |
LWL: | 57′ 3″ (17.45 m) |
BEAM: | 18′ 0″ (5.49 m) |
DRAFT: | 6′ 8″ (2.02 m) |
DISPL.: | 138,000 LBS. (62.6) METRIC TONS) |
WATER CAPACITY (Approx.): | 600 GALLONS (2,271.2 LITERS) |
FUEL CAPACITY (Approx.): | 2,250 GALLONS (8,517.2 LITERS) |
HOLDING TANK CAPACITY: | 120 GALLONS (454.3 LITERS) |
GRAY WATER TANK CAPACITY: | 110 GALLONS (416.4 LITERS) |
Structure
Hull lamination schedule per construction plan
Vinylester resin used in first 3 laminations
All exterior gelcoat White Ferro Super Shield on superstructure and Arocoat brand on hull and non-skid
Deck lamination schedule per construction plan
Core:
Cabin side (vertical surfaces): Foam Gurit-G80 or equivalent cross-linked foam
Cabin top and deck (horizontal surfaces): Gruit cross linked foam per construction plan
Fly bridge deck and arch to be vacuum bagged/infused.
In way of all hardware installations the corecell to be replaced with plywood
Structural bulkheads to use 80 kg/m3 type approved closed cell PVC foam
Deck/hull joint:
Between deck and hull flange: 3M 5200
Inside of joint: Two (2) layers M & W.R.
Mechanical fastening: 1/4″ (6.35 mm) x 20unc stainless steel thru bolt on 6″ (15.2 cm) centers where accessible.
In areas that cannot be accessed self-tapping machine screws to be used
Longitudinal Stringer
Hull: Six (6) full length port and starboard, engine beds and floor stringers – topside stringers – longitudinal and
vertical
Deck: per design
Interior floors: per design – for Saloon and Pilot House floor and forward engine room bulkhead structure
Nidacore composite as done on N80
Ballast: Lead approx. 16,400 lbs (7.44 metric tons)
Gelcoat Colors
Hull: Arocoat #333 putty/gray
Deck: Ferro White with hull color at the bulwark sides of the deck and Fashion boards, per profile drawing
Non-skid: Arocoat #333 putty
Boot-top and flybridge stripes: Arocoat #355 black
Bottom paint
One coat epoxy
Three coats Petit Trinidad, red.
Machinery
John Deere #6090AFM85 w/ M2 rating @ 325HP @ 2200rpm
ZF #ZFW325 3.958:1 reduction transmission
Two(2) x 24 volt 190 amp large case alternator to charge house batteries.
Engine instrument panel: deluxe with instrumentation for oil pressure, water temperature, voltage, revolutions,
hour meter, with alarms x two (2), powerview
Mathers controls in wheelhouse and flybridge .
Fernstrum Grid Cooler – model #D1287U-E1
Propeller shaft: 3″ (8.8 cm) A22HS
Taper details: standard S.A.E. taper
Spurs line cutter on main shaft
Propeller: 4 bladed bronze, 42″ diameter x TBD ” pitch
Stern tube: FRP
Bearings: rubber cutlass type at aft end and 1/2 bearing at the forward end
Stuffing Box: PSS shaft seal with raw water cooling from a dedicated thru hull
Fuel filters: Duplex 75-900 – Racor #75-900FGX2 plus engine mounted filter x one (1)
Dry Exhaust: 6″ (15.2 cm) diameter stainless steel
Flexible section: stainless steel “wrinkle belly”
In line muffler: Harco model #1648VRS6 in-line. Exhaust pipe: stainless steel with slots to deter water
Exhaust to run to top of stack
Drain valve at turn of exhaust to drain off water while vessel is unattended
All components mounted with isolation mounts
Heat insulation material: entire exhaust system including inside upper stack wrapped with custom exhaust
blanket
Engine cooling system filled with suitable mixture of coolant/antifreeze to insure coolant does not freeze for winter shipment (see engine manufacturer specifications for proper coolant mixture and type)
Engine room floors: White- FRP with non-skid – no wood structure used within engine room
Engine room finish: painted white and insulated with Technitron or equivalent fire proof foiled and leaded foam
2″ (5.08 cm) thick. All exposed insulated surfaces lined with solid white Pyrotek like N96
Engine room and laz blowers :
Upper stack exhaust: (2) Dometic 110 volt #F1-11115
Port and stbd aft intake for engine room: (2) Multifan 4E35-K-120V with speed controls
Port and stbd aft intake and exhaust for lazarette: (2) Dayton 110 volt #1TDV2
Dampers for each blower
Engine room door and door from lazarette to engine room DSG with view port on main engine room door
John Deere 4045TFM85 HE 24V Diesel “Wing Engine” – 100 hp @ 2400 RPM with ZF 631V 2.477:1 V-Drive
transmission – Wing controls to be Morse cable
Generator: M844L W2/HE/20KW/1PH/1800RPM northern lights marine generator set 20kw 24v.
Gen-sep exhaust system
24 volt start with two (2) “Group 31” batteries
Centek water lift muffler
Remote control panel located in pilot house
Side Power bow and stern thrusters 15 hp 24 volt 12″ (30.5 cm) tunnel
Four station control – one in pilothouse one on flybridge, aft deck and starboard P/B station
Hypro Marine ECS twin cylinder system compromising:
2 off HM5160/RS/HD ECS rear mount helm with 1” straight shaft
1 off HM5195/18 18m harness 1 off HM5195/14 14m harness
1 off HM5290/24 ECS 24v power pack
2 off HC5373 BA175 9TM Steering cylinder
Steering wheel: 18″ (45.7 cm) stainless steel for flybridge and pilothouse
Emergency tiller: to attach to top of rudder post and stow in lazarette
By-pass valve for emergency tiller steering
Plumbing
Fuel tanks:
Number and capacity: Four (4) main tanks totaling 2,250 gallons (8,517.18 liters) with one (1) centerline aluminum “Day Tank” at 31 gallons (117.3 liters) which will gravity feed from main wing tanks and center tank
FRP construction using fire retardant gelcoat on outside of tanks to meet ABYC standards section H-33.20 for FRP fuel tanks
Inspection plates appropriately positioned for interior access by average size man. Inspection plates to have label with all information stated in ABYC section H-33.16.3 Each internal baffle with a removable panel to allow
access to entire interior of both fuel tanks
Fuel system includes an aluminum supply reservoir, which feeds by gravity from four (4) fuel tanks. Top part of supply reservoir holds approximately two (2) gallons (7.57 liters) and fitted with a sight gauge with a one (1) gallon (4 liter) range and 10th gallon (0.4 liter) marks for fuel consumption checks (supply lines are turned off and fuel is consumed from reservoir). Bottom part of reservoir approximately 29 gallons (109.8 liters) fitted with a drain off at the bottom of the reservoir for water purging and with a water sensor – illuminating a light in wheelhouse if excessive water is present. Reservoir fitted with four draw spigots for main, generator, wing engine and spare – mounted at lower level of reservoir but above water sensing probe. All returns from main, wing and generator plumbed into reservoir
Sight gauges provided for two (2) engine room fuel tanks and vented into main vent system for each tank
Each tank air tested to 4 lbs (0.28 bar) per sq. inch
Provide baffles on 24″ (61 cm) centers with removable panels for access to all areas of tank
A transfer manifold and Walbro (FRB-16-2) 24 volt fuel pump with timer switch and
Racor 900 fuel filter which can transfer fuel from one tank to another and scrub fuel while transferring. Transfer is also used to fill top part of supply reservoir for consumption testing when main fuel tank level drops below the level of the testing part of the reservoir
System to be built per PAE design
Tanks filled with 60 gallons (227 liters) diesel before shipment to U.S. for testing system and running boat from port to port
Fuel pipe and hose:
Supply lines from tanks to supply reservoir are 3/4″ (1.9 cm) I.D. with Aeroquip brand fuel hose and swaged brass fittings
Fuel line from supply reservoir to main engine filter is 3/4″ (1.9 cm) I.D. with Aeroquip brand fuel hose and swaged brass fittings
Fuel lines from supply reservoir to generator and wing engine 1/2″ (1.27 cm) I.D .with Aeroquip brand fuel hose and swaged fittings
Vent lines to be fuel certified, reinforced hose 3/4″ (1.9 cm) I.D. Each tank to have two vents, one forward and one aft
Return lines 1/2″ (1.27 cm) I.D. Aeroquip brand with swaged fittings
Fuel fills 2″ (5.08 cm) I.D. Trident approved fuel hose
Interior surfaces of tanks vacuumed and wiped down prior to final closure to ensure no contaminates enter the fuel system from the tanks
All hardware that comes in contact with fuel bonded into the ships bonding system
Water tanks:
Number and capacity: One (1) baffled tank totaling 600 gallons (2271.25 liters)
FRP construction using FDA approved gelcoat on inside surfaces per plan
Inspection plates: appropriately positioned for access
Each tank air tested: 4 pounds (0.28 bar) per sq. inch
Wema water tank gauges
System built per PAE design
Interior of tanks vacuumed and wiped down prior to final closure
Water hoses:
Cold water: 1/2″ (1.27 cm) diameter PEX
Hot water: 1/2″ (1.27 cm) diameter PEX
Sea water hoses: Trident reinforced rubber certified for marine use and provided with double stainless steelclamps below the water line
Water lines from tank to pump and from pump to accumulator 1″ (2.5 cm) I.D. PEX.
All lines after accumulatorare 1/2″ (1.27 cm) I.D. PEX
Water heater: 40 gallon (151.42 liter) for 220 volt and heat exchanger operation
Thru Hulls and Seacocks: TruDesign non-metalic with load bearing collars to meet ABYC H-27 standards
Each thru hull to have a clearly visible tag indicating its function
Fresh water pressure pump: Head Hunter “Mach 5” #M5-115 , 115 volt
Accumulator tank: One (1) Headhunter model #AVF-4
Plumbing fixtures:
Head sink: Nantucket model #UM-16×11-W, color white x three (3)
Galley sink: Kohler K-3351 double stainless steel side by side
Head faucets: Grohe Eurosmart model #32877 00A
Galley faucet: Grohe Eurosmart model #30306000A
Shower fixtures: Grohe Europlus model #19878000 shower mixer, #35026000 rough in valve, #27242001 shower
set w/ hand shower, hose and shower bar, #28672 wall supply elbow.
Aft deck console: E2 Stainless facuet model #LAV-736 w/ Elkay #ELU 129 sink
Fresh water wash down fittings: Scandvik #10175 stainless steel hose spigot x four (4) (aft deck, foredeck, engine room and boat deck)
Gray water tank:
Galley sink, head sinks, shower sumps and washing machine drain to 110 gallon (416.4 liter) sump tank. Each drain has an appropriate water trap to control odors. Sump includes Sealand Tank Watch 4 24 volt level indicator and a Sealand T24 waste pump fitted with an 24 volt Ultra Jr. pump switch #WPS-02-24/32 and auto/manual control panel. Whale/Henderson #BP0527 hand operated diaphragm bilge pump installed in line with Sealand T24 for manual pumping of gray water tank.
Bilge pumps:
Electric:24 volt Par 36600 diaphragm with 24 volt Ultraswitch auto switch
Manual: Edson model #638AL operable from main salon
(3) High water bilge pumps – 24 volt Rule 3700 gallons (14,006 liters) per hour (#16A) – mounted in bilge above normal bilge water height including Ultra Sr. pump switch #WPS-01-24/32 and Ultra bilge alarm #WA-201
Toilets:
Tecma fresh water flush only 24 volt
Heads fitted with a Par #45510-1000 Y valve allowing sewage to be pumped overboard or into holding tank
Holding tank: FRP
Holding tank pump: Sealand T-24 24 volt plus Whale/Henderson #BP0527 hand operated diaphragm pumpsinstalled in-line with each other.
Holding tank fitted with a deck pump out
Sealand Tank Watch 4 monitoring system
All hoses throughout boat Trident brand with CE approval – where practical
Steering
Hypro Marine ECS twin cylinder system compromising:
2 off HM5160/RS/HD ECS rear mount helm with 1” straight shaft
1 off HM5195/18 18m harness
1 off HM5195/14 14m harness
1 off HM5290/24 ECS 24v power pack
2 off HC5373 BA175 9TM Steering cylinder
Steering wheel: 18″ (45.7 cm) stainless steel for flybridge and pilothouse
Emergency tiller: to attach to top of rudder post and stow in lazarette
By-pass valve for emergency tiller steering
Electrical
Electrical panel set consisting of the following:
AC/DC Electrical distribution panel x one (1)
Parallel switch for emergency engine/house battery paralleling x one (1)
Engine and generator battery shut off switch and panel
Parallel switch for emergency generator/house battery paralleling x one (1)
Shore power inlets and AC system
SmartPlug #BM50S stainless steel 50 amp 3 pole 4 wire 120/240 volt AC 60 Hz
SmartPlug #BM30S stainless steel 30 amp 2 pole 3 wire 120 volt AC 60 Hz
Olsun isolation transformer SGS 12 YY-0-15
All galley and head outlets run through a GFCI type outlet
Battery and DC system
Eight (8) x 255+ AH (8D) Lifeline batteries in series (2 banks of 4) for 24 volt house service (1020 amp hours) and two (2) additional 4Ds in series for 24 volt engine starting for each main engine. The engine starting batteries are isolated from the house batteries, preventing inadvertent discharge of the engine starting batteries. Main engine has dual alternators: Two (2) x 190 amp large case for charging house bank and for charging engine battery. Parallel switches provide for emergency engine starting
One (1) x “Group 31” Lifeline battery in pilot house for house 12 volt service – with 70 amp 24/12 voltage
converter
Each battery secured with stainless steel tie down beams
Battery cable: “00” for general battery leads with “0000” for starting and other heavy load items with longer runs
Positive lead – red
Negative lead – yellow
All wiring used throughout boat color coded – all wire supplied by factory to be tinned wire
Conduits for future installations
PVC from arch/mast to pilothouse
PVC from engine room to pilothouse
PVC from aft corners of salon overhead to engine room
Electrolytic control:
All hardware mounted below waterline i.e. Bow thruster,propeller shafts, rudders, supply reservoir and fuel
manifolds, engines etc. grounded into bonding system
Zinc plates – Three (3) x 2-1/2″ x 5-3/4″ (6.35 cm x 14.6 cm) tied into the bonding system
Inverter -2 x 5000 watt / 24V inverter/battery charger included with remote panel at pilothouse
Interior Finish and Interior Equipment
General
Joinery work to be horizontal grain Teak, Cherry or Moabi veneer with N59 style square moldings, door
frames,cabin doors and fiddles
All drawers to have Blum stainless steel slides
Overhead panels held in place with “Fast Mount” system.
Galley
Refrigerator and freezer: 32″ Fisher & Paykel #RS32A72J1 with icemaker and custom integrated teak doors with
Avio-Diepen locks
Countertops: Formica brand solid surface ‘Arctic’ #102 – 1 1/2″ thick at edges squared edge detail with 3/4″
overlap to cabinet face below
Floors: tile from Taiwan supplier
Cabinetry/paneling – horizontal teak with satin varnish
Cook top: Fisher & Paykel 30″ Induction cook top 4 zones #CI304DTB2 N, 240volt
Oven: 30″ Fisher & Paykel 9 function self cleaning # OB30SCEPX3 N, 120 – 240 volt
Microwave: Over range Fisher & Paykel #CMOH30SS-2 Y
Trash compactor – 15″ – GE model UCG1680LSS
Overhead: individual padded Majilite vinyl panels secured in place with Fast Mount” fasteners and easily
removable for service of deck hardware and wiring
Locker interior finish: Formica
Dishwasher: 18″ built in Bosch 800 series stainless steel #SPX68U55UC
Main Salon
Floors: 3″ Teak or Cherry planking with microgrooves
Cabinetry/paneling: horizontal teak with satin varnish
Dinette table: Teak or Cherry
Furniture: settee as designed with all detail as shown in layout drawing includes Ultra Leather fabric
Overhead: individual padded Majilite vinyl panels secured in place with “Fast Mount” fasteners and easily
removable for service of deck hardware and wiring
Locker interior finish: Formica
Teak valance and air con soffits over windows
“Ekornes” Stressless Consul – teak finish – Batick leather chairs x two (2) – color choice Cream, Brown, Black,
Burgundy, Latte
GE Wine Center model #GWS04HAESS starboard forward
Two (2) bar chairs/stools (Buyer supplied)
Master Cabin
Floors: 3″ Teak or Cherry planking with microgrooves
Cabinetry/paneling: horizontal teak with satin varnish
Overhead: individual padded Majilite vinyl panels secured in place with Fast Mount” fasteners and easily
removable for service of deck hardware and wiring
Locker interior finish: Formica
Standard Queen mattress
Horizontal staving along the hull side at the head of master berth to be FRP painted to match overhead color
Counter tops – teak
Heads
Floors: tile from Taiwan supplier
Countertops: Formica brand solid surface ‘Arctic’ #102 – 1 1/2″ thick at edges squared edge detail with 3/4″
overlap to cabinet face below
Mirrors in front of sink. Opening doors and vanity lights along sides of doors
Shower in master with two shower heads and mixers – solid surface floor and seat top, glass door, and upper
locker forward. Showers in forward guest and wheelhouse with FRP pan and bi-fold door
Overhead: individual padded Majilite vinyl panels secured in place with Fast Mount” fasteners and easily
removable for service of deck hardware and wiring
Locker interior finish: Formica
Exhaust blower: One (1) Soler & Palau #TD-100 110 volt blower on 30 minute timer
Stainless steel towel bars
Cabinetry: horizontal teak with satin varnish
Door to owner’s shower frameless glass.
Forepeak
Painted with gray gelcoat
Drain to thru-hull through boot top
Pilothouse
Floors: 3″ Teak or Cherry planking with microgrooves
Cabinetry/joinery work: horizontal teak with satin varnish
Countertops and dash panels: black formica
Overhead: individual padded Majilite vinyl panels secured in place with Fast Mount” fasteners and easily
removable for service of deck hardware and wiring
Table: teak
Locker interior finish: Formica/painted wood
Cushions with Ultra Leather upholstery
Chart light: LED, 24 volt
Teak louvers on tops of console for ventilation of electronics
Chart table with drawers and storage under
Stidd helm chair #500N-200-X2 “Slimline”
One Ritchie 4.5″ compass Does not include swinging compass
Forward Guest Cabin
Floors: 3″ Teak or Cherry planking with microgrooves
Cabinetry/paneling: horizontal teak with satin varnish
Overhead: individual padded Majilite vinyl panels secured in place with Fast Mount” fasteners and easily
removable for service of deck hardware and wiring
Locker interior finish: Formica
Queen mattress
Book shelves starboard aft end above desk
Horizontal staving along the hull sides at berth to be FRP painted to match overhead color
Counter tops teak
Desk with swing-out chair starboard aft. Covered in Ultra leather
Pilothouse Guest Cabin
Floors: 3″ Teak or Cherry planking with microgrooves
Cabinetry/paneling: teak paneling – horizontal teak with satin varnish
Overhead: individual padded Majilite vinyl panels secured in place with Fast Mount” fasteners and easily
removable for service of deck hardware and wiring
Mattress: foam with vinyl cover
Locker interior finish: Formica
Utility Room
Port side work bench with formica top
Floor: Lonseal – Loncoin II
Cabinetry/paneling: white Formica paneling with teak trim
Overhead: individual padded Majilite vinyl panels secured in place with Fast Mount” fasteners and easily
removable for service of deck hardware and wiring
Locker interior finish: Formica
Washer -Bosch model #WAT28400UC Drain to gray water tank
Dryer -Bosch model #WTG86400UC ventless condensing installed in locker with door. Drain to gray water tank
Freezer – Summit front loading 24″ Model # TBD
(7) Kidde – Battery operated combination smoke and CO alarms installed in the accommodation areas
(bedrooms, salon, lounges, pilothouse, galley, long hallways)
All intererior locker doors and drawers to have square body push button latches. Drawers to have stainless
steel “Blum” sliding hardware
All interior stateroom doors – Squared with no lower threshold like the N59. Doors to be cored like the N59 for
weight savings. Includes rubber gaskets for sound reduction and Mobella “McCoy Star Square” door handles with privacy locks
All hanging lockers lined with cedar and to have 24vdc lighting with auto switch
All hand rails shown on drawing included
Lighting
Main overhead lighting throughout: LED – SS – warm white – 24 volt with wall switches for each designated area.
(approximately 70)
Exterior courtesy lights – LED x fourteen (14)
Engine room lights: (4) x 24 volt Settway model #SETC11126A LED & (6) x 24 volt Settway model
#SETC11126A LED machinery lights in the engine room with switch forward and aft
Exterior lights: LED 24 volt. Two (2) on upper aft deck, six (6) over the cockpit, and two (2) on side deck, (2) in
flybridge arch
Navigation lights: 24 volt Hella NaviLED Pro (port, starboard, stern, masthead, and anchor)
Owners cabin reading lights: 24 volt chrome x two (2)
Courtesy lights: LED x thirty two (32) 24 volt
Vanity lights: LED 24 volt (2 at owner’s sink)
Forward guest cabin reading lights: 24 volt chrome x two (2)
Overhead reading lights: LED 24 volt
Deck flood lights: Two (2) Aqua Signal 120 volt / 500w series 1069 mounted on port and starboard stack
spreaders
Hanging locker lights: LED, 24 volt approx. 7
Exterior Finish and Exterior Equipment
All horizontal surfaces on deck have a Gibco #GFD102N diamond pattern non-skid as shown in deck plan.
Standard non-skid is a contrasting color to parameter deck
Chocks for mooring lines:
Transom: stainless steel with attached cleat – recessed x one (1)
Cockpit sides: stainless steel with attached cleat – recessed x two (2)
Amidships: stainless steel with attached cleat – recessed x three (3) – One on port side and two on starboard side
Bow: stainless steel bollard style x four (4)
12″ (30.5 cm) stainless steel cleat at bow x two (2)
Lower and upper rubrails FRP with a solid stainless steel cap – rub rails integral to hull
Hull windows/ports -two (2) 20″ x 38″ rectangular glue in windows in the owners cabin and nine (9) 13″ x 23″ rectangular glue in windows (one (1) in the galley and two (2) in the owners cabin head/shower and one (1) in fwd guest cabin head and five (5) in the forward guest cabin) – (2) 12″ round stainless steel ports (one in the
pilothouse head/shower and one in the captains cabin)
Bow roller: FRP and stainless steel double bow roller with bronze rollers to accommodate a 170 lb. (77 kg)
Rocna type anchor on starboard roller and the port roller to be designed for a second light anchor or for mooring lines. Roller on starboard side slotted for chain and the port roller smooth for line
Stainless steel stanchions around foredeck 1-1/4″ (3.2 cm) diameter.
Maxwell 24 volt VWC 3500 windlass with 1/2″ (1.27 cm) HT chain wheel, mounted on a molded FRP base
Chain: Install 400′ – 1/2″ HT (122 m – 1.27 cm) chain
Maxwell chain stopper mounted on bow roller
Anchor: 170 lb. (63.5 kg) Rocna
Hatches: Foredeck hatch one (1) Lewmar #Ocean 60 with Oceanair screen. One (1) Freeman #18HAALR over
chain locker. Skylight hatch in aft side of bridge, over master room vanity Lewmar #Ocean 30 with Oceanair screen
One (1) Soler & Palau #TD-100 110 volt blower to provide forced ventilation from inside Portuguese Bridge to
owner’s cabin
Davit – Steelhead Esprit 1500 lb (680 kg) – full extension to 12′ (3.66 cm) – Four function hydraulics (luffing,
winch, telescoping, and rotation) with 24 volt HPU
Windshield wipers – AM Equipment 2-speed 24 volt with auto park #RC524992, #EX2108 pantograph arm x four (4), with 24 volt window wash system, wiper control panel #EX2160604 for four (4) motors
Horn: Kahlenberg D0A double air horn, compressor/tank kit, and 24 volt solenoid valve
Aft deck:
FRP console with sink, faucet and locker port side. Electri-Chef Electric BBQ Model #4400-EC336-IM-24
Hatch to lazarette with gas shocks and locking mechanism.
Shower Scandvik recessed shower #12141
Windows and doors:
Wheelhouse and salon windows to be frameless glue in with fritting
Wheelhouse doors: welded aluminum – Dutch – four hinged door with upper and lower dogs in addition to deadbolts and locksets. R250 series – door #9 21″ x 72″ (53.3 cm x 182.88 cm) left and right
Salon door: Welded aluminum Dutch door with full ht. glass panels per GA
Transom door: Hinged inboard “blind” dog set to secure door
Foredeck seating: White vinyl cushions with closed cell foam
Portuguese bridge locker with double doors accessed from inside P/B
Four removable “U” shaped stanchions for swim step 2″ diameter SS
Stainless steel telescoping swim ladder mounted on the underside of the swimstep
Stainless step into lazarette
Flybridge:
Engine controls: Mathers
18″ (76.2 cm) stainless steel wheel
Engine control panel, horn switch, windlass control
Settee with FRP table and white vinyl cushions
Pompanette helm chair #T-2017W
Stainless steel ladder with FRP steps to boat deck
All rails and venturi as shown on design
Starboard settee at forward end of F/B with white vinyl cushions with closed cell foam
FRP hardtop with SS supports, mounting platform for radar, and (5) overhead lights. White with painted non skid
on top
FRP exhaust stack with winglets for mounting electronics
Deck drains:
Foredeck/ anchor well: Two (2) 2″ (5.08 cm) scupper drains through boot top port & starboard and two (2) aft at
fwd end of P/B to drain through boot top P&S.
Cockpit, stbd walkway, and foredeck: (7) large freeing ports to drain large amounts of water. Cockpit and stbd
walkway freeing ports to include hinged FRP flaps
Boat deck: Four (4) total 2″ (5.08 cm) scupper (2 ea) P&S
Flybridge: Two (2) total (1 ea) P&S
All exterior locker doors to use Perko fig.777 flush hatch dogs
All exterior door keeps ABI #2039CH
NORDHAVN nameplates
* Specifications are subject to change at the discretion of designers and builders
Additional items to be included in standard pricing
Air conditioning: DometicTempered Water system with heating system tied in.
Stabilization: Humphries 24vdc Electric fin system for underway and at rest.
Fin – Twin kit 1.0 Yacht, 10.7 sq. ft. fins
FIN CF553-060
Servo unit (SU553)
Mounting kit GRP hull (SU553)
Outer flange kit (SU553)
RCU 551
Active+ yacht (software)
Installation kit (SU553) HCS5 Eng.
HCS configuration software
HCU/RCU Adapter kit
HCU/RCU Cable 1.5m (cable E)
Servo cable 8m (cable C
(2) pop-up cleats on swim platform.
Electronics pakage per Alcom Marine quote dated April 14,2020 Bid # B37179-C
SEAFIRE FD1300m fire system installed in engine room with relay box to shut down main engines, gen set and
blowers. Includes pull cable and alarm.
SEAFIRE FD1050 in lazarette
SEAFIRE FD900m fire suppression system in forward bilge
Oil change system – hard plumbed into the ain engine, Wing engine and Generator
Add aft cockpit control pod – Mather control head, thruster jog levers and windlass control
Wing control station on starboard sidePortuguese bridge – includes Mathers control head, thruster jog levers,
windlass control.
Lightning ground with #2 wire and Forespar wand
Vacuum gauges on all Racor filters (x3)
Install isolation valves, both hot and cold at every sink, shower, toilet, dishwasher etc.
Sight gauge valves to be lever style ball valve in lieu of gate valve – main port, main stbd and supply tank ( x3
Apollo)
Dometic Sea Xchange SX semi-automated SXII600Z watermaker (600 gpd) #2524030387 – 240vac – frame unit
installed in the lazarette
Garbage disposal in galley sink with three way valve to pump directly overboard or to gray tank (part Evolution
Excel)
Magnetic catches on interior doors
Lock on lazarette hatch
2 x “L” shaped hand rails on port and stbd stern
Add secondary deck pipe and 18” shelf – port side – in chain locker with ‘lip’ for secondary rode
Extended FRP swim step
News
NORDHAVN 62501
Model: Nordhavn 625
Hull no:01
Sales office:
Nordhavn Southwest
N625-01 arrives in Dana Point, CA for commissioning
Nordhavn is excited to welcome the brand new N625-01 to its headquarters in Dana Point,
We are getting excited for the launch of the brand new Nordhavn 625!
https://www.youtube.com/watch?v=-Czt4rSF0Fc
First Nordhavn 625 splashes
Hull #1 nearing completion The Nordhavn 625 splashed into the test tank at the South
Nordhavn Profiles: The Taiwan Factories
https://www.youtube.com/watch?v=2GHla40iaNA
Nordhavn announces the N625 and the N71
Dana Point, CA – (March 17, 2021) – Pacific Asian Enterprises, Inc. (PAE) is excited
Introducing the brand new Nordhavn 625: a twist on the proven Nordhavn 60 hull.
What helps keep Nordhavn at the top of its game is the continual push to
New models: N625 and N71
Pacific Asian Enterprises, Inc. (PAE) is excited to announce the addition of two new models
